Compressors - your air supply

A placeholder for compressor info - looking for someone to help round this out.

Usual commercial advice:

Size: add up all the CFM requirements of the tools that will be on the compressor at one time and get 20% more "delivered" or "free" volume not "displaced" volume




EXAMPLE:

compressorbrightThe photo on the right is of  (what I think is) a homemade set-up - aquired it at an estate sale in 2005.

On top is a two stage Ingersol-Rand compressor specs say: 17.5cfm at 90 PSI (220V 15amp). It's sitting on a 60 gallon horizontal storage tank.

The air intake is modified (thanks to Sabah and Stuart Kendall) commercial truck filters and a couple of pizza pans.  Noisy but it works.

The tank at 110PSI - (use a regulator at tool end)  can run a Trow and Holden B & D air hammer all day, it just cycles every once in awhile.  Also runs a polisher and again it cycles -- just more frequently.  Die grinders it keeps up with, BUT big air grinders (from Boeing Surplus) - it barely keeps up with.
